Product features:
1. Fully DC inverter, high efficiency
2. Mitsubishi inverter Compressor
3. DC inverter fan motor+ super low noise
4. WIFI function included(control heat pump with your cellphone easily)
5. 3 years warranty
| Model No. | ENE-070TA1 | ENE-103TA1 | ENE-136TA1 |
| Power Supply | 380～415V / 3/50Hz | ||
| Heating Capacity at Air 26℃, Water 26℃, Humidity 80% | |||
| Heating Capacity（kW) | 70～16.5 | 103～24.8 | 136～32.4 |
| Power Input（kW) | 10.03～1.02 | 14.80～1.54 | 19.46～2.01 |
| COP | 16.11～6.98 | 16.09～6.96 | 16.15～6.99 |
| Heating Capacity at Air 15℃, Water 26℃, Humidity 70% | |||
| Heating Capacity（kW) | 51～12.1 | 76～18.3 | 101～23.9 |
| Power Input（kW) | 10.24～1.6 | 15.29～2.42 | 20.24～3.15 |
| COP | 7.56～4.98 | 7.55～4.97 | 7.59～4.99 |
| Cooling Capacity at Air 35℃, Water 27℃ | |||
| Cooling Capacity（kW) | 38～9.1 | 58～14.1 | 76～18.5 |
| Power Input（kW) | 10.41～1.36 | 15.89～2.11 | 20.65～2.74 |
| EER | 6.69～3.65 | 6.68～3.65 | 6.74～3.68 |
| Rated Power Input（kW) | 10.0 | 15.0 | 20.0 |
| Rated Current(A) | 18 | 27 | 36 |
| Max Power Input（kW) | 15.0 | 22.0 | 30.0 |
| Max Current(A) | 26 | 38 | 54 |
| Refrigerant | R32 | ||
| Compressor Type | Mitsubishi inverter | ||
| Heat Exchanger | Titanium | ||
| Expansion Valve | Electronic EEV | ||
| Air Flow Direction | Vertical | ||
| Water Flow Volume（m3/h) | 20 | 30 | 40 |
| Net Dimensions(L*W*H)（mm） | 1416*752*1055 | 1250*1080*1870 | 2150*1080*2180 |
| Package Dimensions(L*W*H)（mm） | 1580*880*1150 | 1300*1100*1950 | 2230*1120*2200 |
| Working temperature range（℃） | -15～43 | -15～43 | -15～43 |
| Heating temperature range （℃） | 15～40 | 15～40 | 15～40 |
| Cooling temperature range （℃） | 8~28 | 8~28 | 8~28 |
| Noise（dB) | ≤59 | ≤62 | ≤65 |
| Net Weight（kg） | 280 | 420 | 750 |
| Gross Weight（kg） | 320 | 460 | 810 |
| Water connection(mm) | 63 | 63 | 75 |
